| Product Name：4 inch 9W Dimmable LED Downlight |
| Model No：IL-TDB4L-P09 |
|
Place of origin：China Price Terms：EXW Payment Terms： T/T, Paypal, Western Union, L/C Package：20pcs/ CTN Minimum Order： 50pcs Delivery Time：3-5 days Brand Name：inlumi lighting (OEM/ODM) |
4 inch
9W Dimmable Led Downlight
1). It can be made from 4W to 30W (2.5 inch -10 inch are
optional)
2). 3 YEARS WARRANTY
3). High CRI, Ra>80
4). High PF, PF>0.9
5). CE & Rohs Approval
Specification of 4 inch 9W
Dimmable Led Recessed Downlight
| Item | Technica Data | Item | Technica Data |
| Led Type: | 2835 SMD | Beam Angle: | 160 degree |
| Power: | 9W | Lumen: | 780LM |
| Input Voltage: | AC90-277V | CRI (Ra>): | 75-80 |
| Working Temperature: | -20-45 degree | Working Life: | 50000H |
| Frequency: | 50/60HZ | Operation Humidity: | 10%-90% |
| Color Temperature: | 2700-7000K | Power Factor: | >0.85 |
| Product Size: | φ130xH65mm | Hole Size: | φ115mm |
TDB Series 2835SMD 4 inch 9W Dimmable Led
Ceiling Downlight
| Model No. |
Watt (W) |
Lumen (LM) |
Dimension | Hole Size |
Input Voltage |
| IL-TDB2H-P04 | 4W | 340LM | Φ90xH54mm | Φ75mm | AC90-277V |
| IL-TDB4L-P09 | 9W | 780LM | Φ130xH65mm | Φ115mm | |
| IL-TDB5L-P12 | 12W | 1050LM | Φ160xH65mm | Φ145mm | |
| IL-TDB5H-P15 | 15W | 1300LM | Φ180xH74mm | Φ165mm | |
| IL-TDB6L-P18 | 18W | 1600LM | Φ190xH80mm | Φ180mm | |
| IL-TDB8L-P24 | 24W | 2040LM | Φ230xH85mm | Φ205mm | |
| IL-TDB8H-P24 | 24W | 2040LM | Φ240xH70mm | Φ220mm | |
| IL-TDB10L-P30 | 30W | 2550LM | Φ300xH100mm | Φ260mm |
Features:
1). General Indoor
Illumination
2). No Infrared and UV
3). Aluminum Reflector to Reduce
Glare
4). Super bright, high
energy-saving
5). High power Bridgelux 45MIL chips with 100-110LM/W
6). Epistar & Bridgelux chips and Isolated Driver promise high quality
7). All Models can be Dim to 0%-100% with
Universal or Trailing Edge Dimmer
8). No RF interference, No flickering
9). No mercury and other hazardous
materials fully RoHS-compliant
Package
Details:
| Available: | Exported Standard Neutral White Box/ Neutral Color Box/ Customized |
| Inner Box Size: | 140x140x80mm |
| Master Carton Size: | 715x295x420mm |
| Qty/CTN: | 50pcs |
